TM 5-3805-248-23-2
SUPPLEMENTAL STEERING PUMP REPAIR - CONTINUED
0379 00
ASSEMBLY - CONTINUED
7.
Position retainer (80) in bore of valve body (4), align-
4
80 (HIDDEN)
ing center bore of retainer (80) with stem of piston
(85).
394-1530
8.
Position spacer over retainer (80). Spacer must be
80
1-1/8 in. OD (2.85 cm), 1/2 in. (1.3 cm) ID and 1/8 in.
(0.32 cm) thick.
85
81
82
83
84
394-1532
0379 00-12
